CP KA24DE Pistons and KA24E Pistons

CP Nissan KA24DE Pistons

Do you want more horsepower and torque from your engine? We have the solution with these CP Pistons high performance KA24E and KA24DE forged pistons which are compatible with stock and oversized valves as well as stock and high lift camshafts. These superior piston sets are available for use with turbochargers, superchargers, nitrous and normally aspirated engines.

CP Carrillo products represent the highest quality and are engineered for maximum power. Pistons can be ordered with gas ports, skirt coating, ceramic top coating, and stronger wrist pins if desired. To order a set with any of these options, please include a message in the note section of the order form during our check out process, or you may contact us in advance for more info on these options.

KA24E and KA24DE CP Pistons Standard features include:

  • Deep valve reliefs accommodate high lift camshafts
  • Larger valve reliefs for +1mm valve sizes
  • Custom skirt cam and barrel design
  • Accumulator grooves
  • High strength aluminum forgings
  • High performance rings included
  • Fully CNC machined and balanced to +/- 1 gram
  • Wrist pins included at no additional cost
  • Double pin oilers force fed from oil ring groove
  • Pick lock grooves for easy lock removal
  • Pin fitting included

CP Pistons Nissan KA24DE and KA24E Forged Pistons and Ring Set Specs

KA24e and KA24DE Forged CP Pistons

  • Bore Size Cylinder bore size piston is designed to work in, listed in inches and millimeters
  • Relative Size Denotes whether this bore size is stock standard size, or an oversize listed in millimeters
  • CR Compression Ratio
  • Crankshaft Stroke Crank stroke the pistons are designed to work with.
  • Connecting Rod Length Designed to work with stock rod length of 165mm
  • Wrist Pin Diameter 21mm
  • Compression Height This is the distance from the centerline of the wrist pin bore to the top flat surface of the piston.
  • Ring Widths Ring grooves are machined to work with 1.0mm, 1.2mm, 2.8mm rings
  • WHAT’S INCLUDED 4 forged pistons, 4 Wrist Pins, pin retention locks and premium piston ring set



Bore
Inches
Bore
MM
Size
MM
Stroke
MM
Rod
Length
MM
C.H. Compression Piston Set
3.504 89.00 STD 96.0 165 1.339 8.0(E)/9.0(DE) SC7299

Add To Cart
3.524 89.50 +0.5mm 96.0 165 1.339 8.0(E)/9.0(DE) SC7300

Add To Cart

More general and technical information about CP Carrillo and our complete listing of all available CP products is here CP Carrillo Forged High Performance Engine Pistons

Custom Nissan KA24 Pistons

If you do not see a shelf stocking part number set here with the specifications that you need, we can provide you with a set of custom pistons built to your exact requirements. Please contact us for assistance with custom pistons and we will be happy to work with you to insure you get exactly the forged KA24 pistons that you require for your engine.
