CP Subaru BRZ and Scion FR-S FA20 Pistons

cp pistons turbo BRZ and FR-S FA20 engine piston

CP Pistons brand FA20 pistons provide superior performance in high performance and racing FA20 engines. This engine as used in the Subaru BRZ and Scion FR-S is a spirited performer right from the factory. In the quest for more power, more turbo boost and or nitrous is often used. In order to safely produce more power, a top quality forged piston and ring set is required.

CP FA20 turbo pistons are forged 2618 alloy and are engineered for maximum performance and durability in the most demanding applications. These pistons are compatible with oversize valves and higher lift cams.

FA20 Turbo engine pistonStandard Features Include:

  • Deep valve relief depth accommodates high lift camshafts
  • Made to accept up to +1mm oversize valves
  • Custom skirt cam and barrel design
  • Accumulator grooves
  • High strength aluminum forgings
  • Wrist pins are CP-Carrillo’s 51 series high strength steel pins
  • High performance CPN ring set which includes a gas nitride steel top ring, taper hook groove second ring, and low tension oil ring.
  • Fully CNC machined and balanced to +/- 1 gram
  • Wrist pins and pin fitting included at no additional cost
  • Double wrist pin oilers, force fed oil ring
  • Pick lock grooves for easy lock removal

FA20 Scion FR-S and Subaru BRZ Piston Sets

Each set includes 4 forged pistons, 4 wrist pins, pin lock rings and premium CPN series piston ring set

  • Bore: Cylinder bore size piston is designed to work in
  • Size: Piston size, standard or oversize, in millimeters
  • CH: Compression Height
  • CR: Compression Ratio based on stock cylinder head
  • Notes: Suitable for use with Nitrous, Turbo or Supercharger
FA20         SC7402
Contact us for availability!

More information about CP and our catalog index is available here: CP Carrillo Pistons
